Impeller, Waterway SVL56/Champion, 2.0 Horsepower, High Head : 310-7440

Impeller, Waterway SVL56/Champion, 2.0 Horsepower, High Head Waterway SVL56/Champion Pump Impeller Closed face impeller made for the SVL56/Champion pump by Waterway Plastics. Rated at 2.0hp, it is used in a Waterway SVL56 and Waterway Champion Pool pump body, and must be installed on a 2.0hp (or greater) square flange motor with a threaded shaft. Shaft seal sold separately Impeller Type: Closed Face Impeller Diameter OD: 4-7/8" Vane Width ID: 5/16" Eye Diameter OD: 2-3/16" Eye Length: 9/16" Impeller Width OD: 5/8" Seal Seat Depth: 1-1/16"Shaft Length: Shaft Diameter OD: 5/8"Seal Seat Diameter OD: 1-1/2"Manufacturer: WaterwayPump Application: SVL56 High Pressure Replaces 3107440,314667,5033-82,809105232190,WW3107440B,WWP-101-7440,
