Wet End, Gecko AquaFlo FMXP2 2.0hp 2"mbt 6.1"dia 56fr : 91041622-000

Wet End, Gecko AquaFlo FMXP2 2.0hp 2"mbt 6.1"dia 56fr Note: This is a 6.1 wet end. If you need a 6.3 wet end see 34-402-1252 - Wet End, Gecko AquaFlo FMXP2, 2.0hp, 2", 6.1"dia, 56fr56 frame spa wet ends can have one of two designations - 6.1 or 6.3. The difference is the measurement between the top two thru-bolts. 6.1 wet ends measure 4" and 6.3 wet ends measure 4-1/8". See diagram below. Manufacturer: AquaFlo/Gecko Pump Model: Flo-Master XP2 Motor Frame: 56 Frame Thru-Bolt- 4" Spacing Drain Plug Location: 4,6,9 o`clock Suction Style: Center Suction Connection Type: Male Buttress Thread (mbt) Suction Pipe Size: 2"Discharge Style: SideDischarge Connection Type: Male Buttress Thread (mbt)Discharge Pipe Size: 2"Horsepower: 2.0hpVolute Fastening Type: 8 Screws Replaces 389566,91041622,
