Motor, US Motor, 1.0hp, 115/208-230v, 56JFr, C-Face, Full, PE : ASB654

Motor, US Motor, 1.0hp, 115/208-230v, 56JFr, C-Face, Full, PE C-Face Pool & Spa Motor - Full Rated, Premium Efficiency Switchless Design, 6.5" Frame Diameter: Category "S" & "J" FEATURES: Two Compartment Shaft Threads - 7/16-20 UNF-2A 50°C Ambient Triple Bearing Protection 1081 Design Continuous Duty Voltage Selection Device (Dual Voltage Only) Class B Insulated Open Dripproof Sealed Ball Bearings Switchless Design 303 Stainless Steel Shaft Thermally Protected 6.5" Diameter Frame Motor Type: Pool Motor Amperage: 14.4A/7.6A-7.2A Voltage: 115v/208v-230v Phase: 1 Phase (1ph) Frame Type: 56J Speed: 1 Speed (1-Spd) Horsepower: 1.0hpTotal Horsepower: 1.4thpMotor Shaft Type: ThreadedMotor Style: C-FaceCapacitor On Top: NoManufacturer: Nidec-Motor-Corp/US-Motors Replaces 38560,
